Details
Mako utilizes ISB VMax stainless steel bearings, which feature a specific “full ball” structure to work optimally inside the suspension pivot linkages. These specially-chosen bearings offer 40% more loading capacity than conventional bearings, offering greater resilience and reliability.
ICS2 internal cable routing technology ensures maximum protection of cables and hoses while offering clean lines from the handlebar to the rear derailleur.
Mako comes complete with a provision for FOX's Live Valve electronic suspension system. The frameset features integrated mounting points for the control unit and sensors, marrying Mako and state-of-the-art active suspension technology together.
Mako uses our Anti-Mud System (AMS) to minimize resistance and accumulated weight caused by the build-up of mud. Increased tire clearance and optimized tube shapes to reduce this build-up, improving ride efficiency and speed wherever you go.
- ISB VMAX Bearings
- ICS2 Internal Cable Routing
- FOX Live Valve Ready
- Anti-Mud System (AMS)
Specs
Frame | Mako 3, Down Country Geometry BGC, kinematic XCO WC 105mm, Full carbon HMR2X, Triple monocoque, Resin Matrix Nanotech CNT, bearings full ball ISB VMAX, BB92 bottom bracket, Active Stay, Asymmetric, Full internal cable system ICS2, Headset semi-integrated OH2S 1-1/2", Post Mounted brake PMS, 29"x2.35 maximum tyre, BOOST Thru axle 148x12, Fox Live Valve ready, weight 1810g |
---|---|
Fork | Rock Shox SID Select RL, Damper Type Charger RL, 15x110mm Maxle Stealth, Rake 44mm, Tapered steerer, 35 mm straight wall aluminum Fast Black, Lockout remote, weight 1671g, 120mm travel |
Rear Shock | Rock Shox SIDLuxe ULTIMATE BERRIA MAKO 3 WC XCO Tuning, Debon Air, Lockout remote 2 POS adjustment, Trunnion 165X45mm, weight 227g, 105mm travel |
Rims/Wheels | FULCRUM RED METAL 500, alloy, 27 mm internal wide 1950g - 28 (front) 28 (rear), Straight Pull Spokes |
Tires | Vittoria Barzo 2.35"X 29", Tubeless ready, GRAPHENE 2.0 120 TPI, weight 725g |
Crankset | SRAM X1 DUB Eagle Boost 34T 170-175mm |
Chain | SRAM SX Eagle CN-EAGL-SX-A1 |
Rear Derailleur | SRAM NX Eagle, 12 Speed |
Rear Cogs | SRAM XG1210, 11-50T |
Shifters | SRAM NX Eagle Trigger |
Handlebars | Avanforce 2, 31,8mm, wide 780mm |
Stem | Avanforce 3, -6°, Ø31,8, 80-90-100mm |
Brakes | SRAM DB8, 4 pistons, mineral oil, Disc 200/F 180/R |
Saddle | Fizik Taiga alloy rail |
Seat Post | TRANZX JD-YSPJL Aluminum 7075-T6, 0° offset, 31,6 x 421mm, 125mm travel |
Accessories & Extras | UDH Universal Derailleur Hanger |
* Subject to change without notice.
